TS130 - CF/CFC Accessories
Metric Measurements
Name | Item code | For cylinder type | Type | Connection |
TC428 | 14675 | CF/CFC 49kN | Locking pin | - |
TD419 | 14563 | CF/CFC 49kN | Clamp head for piston (max 20kN) | Tap ø19mm |
TD420 | 14562 | CF/CFC 49 kN | Clamp head for cylinder (max 20kN) | Int. UN 1 1/2-16 |
TMC421 | 20234 | CF/CFC 49kN | Coupling tap | Tap ø19mm |
TS430 | 14571 | CF/CFC 49kN | Support plate | Hole ø19mm |
TC128 | 15160 | CF/CFC 111kN | Locking pin | - |
TD119 | 15182 | CF/CFC 111kN | Clamp head for pistons (max 50kN) | Int. NPT 1 1/4-11 1/2 |
TD120 | 15171 | CF/CFC 111kN | Clamp head for cylinder (max 50kN) | Int. UN 2 1/4-14 |
TMC121 | 15198 | CF/CFC 111kN | Coupling tap | Tap ø32 mm |
TMT124 | 15177 | CF/CFC 111kN | Coupling niple | Int. 2x NPT 1 1/4-11 1/2 |
TK107 | 28874 | CF/CFC 111kN | Chain with hook (2m) | |
TOK109 | 15167 | CF/CFC 111kN | Chain yoke | Int. UN 2 1/4-14 |
TS130 | 15172 | CF/CFC 111kN | Support plate | Int. NPT 1 1/4-11 1/2 |
TSM131 | 15151 | CF/CFC 111kN | Support with articulated tap | Ext. NPT 1 1/4-11 1/2 |
TC228 | 15819 | CF/CFC 232kN | Locking pin | - |
TMC221 | 15814 | CF/CFC 232kN | Coupling tap | Tap ø48 mm |
TMT222 | 15817 | CF/CFC 232kN | Coupling tap | Ext. 2x NPT 2-11 1/2 |
TMT224 | 15818 | CF/CFC 232kN | Coupling tap | Int. 2x NPT 2-11 1/2 |
TS218 | 15806 | CF/CFC 232kN | Support plate | Int. NPT 2-11 1/2 |
Imperial Measurements
Name | Item code | For cylinder type | Type | Connection |
TC428 | 14675 | CF/CFC 49kN | Locking pin | - |
TD419 | 14563 | CF/CFC 49kN | Clamp head for piston (max 20kN) | Tap ø0.75in |
TD420 | 14562 | CF/CFC 49 kN | Clamp head for cylinder (max 20kN) | Int. UN 1 1/2-16 |
TMC421 | 20234 | CF/CFC 49kN | Coupling tap | Tap ø0.75in |
TS430 | 14571 | CF/CFC 49kN | Support plate | Hole ø0.75in |
TC128 | 15160 | CF/CFC 111kN | Locking pin | - |
TD119 | 15182 | CF/CFC 111kN | Clamp head for pistons (max 50kN) | Int. NPT 1 1/4-11 1/2 |
TD120 | 15171 | CF/CFC 111kN | Clamp head for cylinder (max 50kN) | Int. UN 2 1/4-14 |
TMC121 | 15198 | CF/CFC 111kN | Coupling tap | Tap ø1.26in |
TMT124 | 15177 | CF/CFC 111kN | Coupling niple | Int. 2x NPT 1 1/4-11 1/2 |
TK107 | 28874 | CF/CFC 111kN | Chain with hook (78.74 in) | |
TOK109 | 15167 | CF/CFC 111kN | Chain yoke | Int. UN 2 1/4-14 |
TS130 | 15172 | CF/CFC 111kN | Support plate | Int. NPT 1 1/4-11 1/2 |
TSM131 | 15151 | CF/CFC 111kN | Support with articulated tap | Ext. NPT 1 1/4-11 1/2 |
TC228 | 15819 | CF/CFC 232kN | Locking pin | - |
TMC221 | 15814 | CF/CFC 232kN | Coupling tap | Tap ø1.89 in |
TMT222 | 15817 | CF/CFC 232kN | Coupling tap | Ext. 2x NPT 2-11 1/2 |
TMT224 | 15818 | CF/CFC 232kN | Coupling tap | Int. 2x NPT 2-11 1/2 |
TS218 | 15806 | CF/CFC 232kN | Support plate | Int. NPT 2-11 1/2 |
